IP-COM F1226P

معرفی محصول

What It Does

F1226P is 24-port smart PoE switch with 2 GE ports, providing 24 10/100 Base-TX Ethernet ports, 2 10/100/1000 Base-T Ethernet ports and 2 1000Base-X SFP ports. 1-24 port supports IEEE 802.3af PoE(15.4W) or 802.3at PoE+(30W) standard and provides DC power and data signal transmission for AP, IP Phone and IP Camera through category 5 twisted pair. Support PoE management, VLAN, Link Aggregation,QoS, MAC address binding, to protect the users` networking privacy and provide DC power for remote devices.  Less wire, easy installation and less time to optimize user` investment.

Product Features

Excellent PoE performance

1-24 port supports IEEE 802.3af PoE(15.4W) and 802.3at PoE+(30W) standard, PoE output full power up to 370W. Providing DC power and data signal transmission for AP, IP Phone and IP Camera through category 5 twisted pair.

Reliable industrial grade design

Quality: Mean Time Between Failures–MTBF：100,000 hours

Stability: 64 byte packet, time delay less than 10ms, packet loss ratio: 0

Restorability: when network is not stable or error occurs, reboot time less than 10s

Normal operating: operating in -10 0C to 45 0C, device service time over 3 years

Flexible ports

Providing 24 10/100Mbps autosensing ports, 2 10/100/1000Mbps autosensing RJ45 port 2*1000Base-X SFP ports and all port support wire-speed forwarding. Flexible ports make users to enjoy seamless connection

Green energy conservation design

Built-in advanced PoE chip with energy-conservation, ports can auto-switch to  energy-conservation status. Support smart fan system. Users can adjust the fan speed according to device temperature to reduce power consumption to reduce operation cost.

Excellent maintenance

Frontpanel switch design,  support auto-adjust and smart power management to setup the priority of power supply at your pleasure. Kinds of networking management such as Web and SNMP make easy maintenance.

Easy smart management

Support easy management, such as QoS, Link Aggregation,VLAN, ACL etc to prevent MAC attack to make you enjoy a security networking
